WERAN WRL-48100RW 51.2V 100Ah LiFePO4 Rack Battery (5.12kWh) – 8000 Cycles, CAN/RS485, Stackable Home ESS

WERAN WRL-48100RW is a 51.2V 100Ah (5.12kWh) rack-mounted LiFePO4 battery designed for reliable home solar storage and small ESS projects. Built with brand-new LFP prismatic cells (no second-life cells) and an intelligent BMS, it delivers long service life with 8000 cycles @80% DOD. The battery supports CAN/RS485/RS232 communication and scalable installation up to 12 units, making it easy to expand capacity as energy demand grows. With high efficiency (99% @25°C/0.5C), natural convection cooling, and optional features such as single-pack aerosol fire suppression, heating function, and Bluetooth, WRL-48100RW is a practical 48V-class battery solution for inverter-compatible residential ESS and distributed energy storage.

Get A Quote

PREV: No previous article
NEXT: WERAN WRL-48200RO 51.2V 200Ah LiFePO4 Rack Battery (10.24kWh) – 8000 Cycles, High Current, Modular Solar Storage

Longer Life and Safer
A+grade LFP Cell
BMS with multi-level protection

Flexible and Expandable
Up to 12 units in parallel

Smart
BMS is capable of intelligent and efficient power output management
Able to charge at nearly 100% efficiency

Easy to Install and Use
Applications: Residential, Commercial, Industrial, Off-grid, Grid tie and Self consumption. Compatible with all 48V inverters that support LFP.

Compliance
UL1973, UL9540A, UL 9540

51.2V100AH and 51.2V200AH Rack Mounted Battery is made of LFP battery, With the advantage of integration, miniaturization, light, intelligence, standardized, environmental protection, it is a key energy storage element in modern energy storage systems. Integrate solar inverters and LiFePO4 battery enclosures into a pre-wired modular system for easier and faster installation.

Product Name WRL-48100RW
Electrical Characteristics
Nominal Voltage 51.2V
Nominal Capacity 100AH
Energy 5120WH
Battery Chemistry LFP Prismatic Cell
Cycle Life 6000 cycles @80% DOD, 25℃/0.5C
Operating Voltage 43.2V-57.6V
Communication Interfaces CAN/RS485/RS232
Scalable Up to 12 units
Expansion function Single-pack level heat aerosol fire extinguishing device/Heating function/ bluetooth
Charge & Discharge
Recommended charging/discharging current 100A
Maximum continuous charge/discharge current 100A
Peak charging/discharging current 250A 10S
Conversion efficiency 99%, 25℃/0.5C
Environmental
Environment Indoor
Charging Temperature

With heating function: -20~55℃;

Without heating function: 0~55℃
Discharging Temperature -20 to 60℃
Storage Temperature

Between 20℃ and 45℃ within three months;

25±3℃ for more than three months
Storage humidity 65+20% RH
Altitude ≤3000 m
Cooling Method Natural Convection
IP Rating IP20
Mechanical
Dimension (LWD) 450*444*133mm
Weight 43.8KG
Installation Wall-mounted/Rack Mount
Certification
Certificate CB, IEC62619, UL1973, UL9540A, CE-EMC, UN38.3, MSDS
