WERAN 595-625W Large-Format Bifacial Solar Panel – OEM Double-Glass PV Module for Utility, EPC and Wholesale Projects

  • Bifacial, TOPCon, N-type
  • Up to 23.1%
  • 595-625 Wp
  • 32.5 kg

▶ High-performance bifacial PV module for utility-scale solar power plants

▶ Advanced HPDC N-type TOPCon cell technology improves module efficiency and power output

▶ High bifaciality and excellent temperature coefficient support higher lifetime energy yield

▶ Dual-glass structure enhances long-term durability and reliability in outdoor environments

Get A Quote

PREV: WERAN 640-670W HPBC 2.0 Bifacial Solar Panel – OEM Back Contact Double-Glass PV Module for Utility and EPC Projects
NEXT: WERAN 640-670W Back Contact Solar Panel – OEM High-Efficiency Single-Glass PV Module for Distribution and Commercial Projects
  • Technology Bifacial, TOPCon, N-type
  • Power Range 595-625Wp
  • Region China
  • Weight 32.5 kg
  • Product Warranty 12 Years
  • Power Warranty 1 Years of 99 %, 30 Years of 87.4 %
  • Panel Efficiency Up to 23.1%
  • Dimension 2382×1134×30 mm
  • Glass Dual Glass, 2.0 mm
  • Temperature Coefficient of Pmax -0.28 %/°C
  • Cell Number 132
  • Bifaciality 80±5%
  • Maximum System Voltage DC1500V
  • Maximum Series Fuse Rating 35A
  • Operational Temperature -40°C ~ +85°C
  • Power Output Tolerance 0 ~ +3%

  • Up to 23.1% module efficiency for higher energy density

  • Advanced HPDC N-type TOPCon cell technology

  • High bifaciality enabling additional rear-side power gain

  • Excellent -0.28%/°C temperature coefficient for stable hot-climate performance

  • 132 half-cell configuration reducing electrical losses and operating temperature

  • Dual-glass structure for enhanced durability and long service life

  • 12-year product warranty and 30-year linear power warranty
WERAN 595-625W Large-Format Bifacial Solar Panel – OEM Double-Glass PV Module for Utility, EPC and Wholesale Projects

Additional Value
30-Year Power Warranty

Mechanical Parameters

Cell Orientation 136 (6×22)
Junction Box

IP68, three diodes
Output Cable

4mm², +400, -200mm/±1400mm

Length can be customized
Glass Dual glass, 2.0+2.0mm heat-strengthened glass
Frame Anodized aluminum alloy frame
Weight 32.5kg
Dimension 2382×1134×30mm
Packaging 36pcs per pallet
144pcs per 20'GP / 720pcs or 576pcs (only for USA) per 40' HC

Electrical Characteristics

STC: AM1.5 1000W/m² 25°C NOCT: AM1.5 800W/m² 20°C 1m/s Test uncertainty for Pmax: ±3%
Module Type LR8-66HGD-595M LR8-66HGD-600M LR8-66HGD-605M LR8-66HGD-610M LR8-66HGD-615M LR8-66HGD-620M LR8-66HGD-625M
Testing Condition STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT
Maximum Power (Pmax/W) 595 452.9 600 456.7 605 460.5 610 464.3 615 468.1 620 471.9 625 475.8
Open Circuit Voltage (Voc/V) 47.78 45.41 47.98 45.6 48.18 45.79 48.38 45.98 48.58 46.17 48.78 46.36 48.98 46.55
Short Circuit Current (Isc/A) 15.8 12.69 15.85 12.73 15.9 12.77 15.95 12.81 16 12.85 16.05 12.89 16.1 12.93
Voltage at Maximum Power (Vmp/V) 39.91 37.93 40.11 38.12 40.31 38.31 40.51 38.5 40.71 38.69 40.91 38.88 41.11 39.07
Current at Maximum Power (Imp/A) 14.91 11.94 14.96 11.98 15.01 12.02 15.06 12.06 15.11 12.1 15.16 12.14 15.21 12.18
Module Efficiency(%) 22 22.2 22.4 22.6 22.8 23 23.1

Electrical characteristics with different rear side power gain (reference to 610W front)
Pmax /W Voc/V Isc /A Vmp/V Imp/A Pmax gain
641 48.38 16.75 40.51 15.81 5%
671 48.38 17.55 40.51 16.57 10%
703 48.48 18.34 40.61 17.32 15%
734 48.48 19.14 40.61 18.07 20%
764 48.48 19.94 40.61 18.82 25%

Operating Parameters
Operational Temperature -40℃ ~ +85℃
Power Output Tolerance 0 ~ 3%
Maximum System Voltage DC1500V (IEC/UL)
Maximum Series Fuse Rating 35A
Nominal Operating Cell Temperature 45±2℃
Protection Class Class II
Bifaciality 80±5%
Fire Rating UL type 29
IEC Class C

Mechanical Loading
Front Side Maximum Static Loading 5400Pa
Rear Side Maximum Static Loading 2400Pa
Hailstone Test 25mm Hailstone at the speed of 23m/s

Temperature Ratings (STC)
Temperature Coefficient of Isc +0.045%/°C
Temperature Coefficient of Voc -0.230%/°C
Temperature Coefficient of Pmax -0.280%/°C
